  • 300TJQ Heavy Duty Submersible Slurry Pump

300ZJQ Heavy Duty Submersible Slurry Pump

Size: 300mm
Capacity: 780-1000m3/h
Head: 18-55m
Max. particles: 50mm
Temperature Range: ≤80°C
Materials: High chrome alloy, Cast iron, SS304, SS316L, Duplex SS etc

Size: 300mm
Capacity: 780-1000m3/h
Head: 18-55m
Max. particles: 50mm
Temperature Range: ≤80°C
Materials: High chrome alloy, Cast iron, SS304, SS316L, Duplex SS etc

√ Temperature sensor
Winding thermostats protect the motor by sending a signal to a relay supplied to the customer that can be used for sounding an alarm or shutting down the unit if internal temperatures exceed safe operating limits.
√ Moisture detector
A twin electrode system provides double protection by detecting moisture intrusion in both the motor housing and the mechanical seal chamber.
√ Mechanical seal
 The Hydroman TJQ pump incorporates a balanced double-seal arrangement in which both sets of seal springs are enclosed in the oil reservoir. Silicon carbide seal faces are subjected to submergence pressure only which greatly extend wear life of the pump. Heavy-duty thrust bearings and shaft are designed to eliminate shaft deflection problems in high density applications.
√ Heavy-duty water end
Standard high chrome iron construction coupled with heavy section thickness provides the ultimate in protection against abrasive wear in heavy slurries.
√ Easy maintenance access
T-bolt construction allows rapid disassembly of the pump end for maintenance access. The heavy-duty impeller is not screwed on, but keyed to the shaft for easy removal and provides protection against movement during reverse rotation.
√ Optional agitator

A robust agitator can be fitted to the impeller eye.

No.

Model

Size

(mm)

Capacity Q

(m3/h)

Head H

(m)

Power P

(kw)

Eff. η

(%)

Speed n

(r/min)

Max. particles

(mm)

Weight

(kg)

1

300ZJQ780-26-110

300

780

26

110

62

980

50

1970

2

300ZJQ1000-18-110

300

1000

18

110

64

980

50

1970

3

300ZJQ800-35-132

300

800

35

132

63

980

42

2000

4

300ZJQ1000-22-132

300

1000

22

132

64

980

50

2000

5

300ZJQ780-50-185

300

780

50

185

60

980

38

3330

6

300ZJQ800-55-220

300

800

55

220

60

980

38

3400

300TJQ Heavy Duty Submersible Slurry Pump is suited for mine dewatering and slurry applications. Fitted with a temperature sensor, moisture detector, mechanical seal, heavy-duty water end and optional agitator, our submersible slurry pumps are designed to be durable in the most trying conditions. The pump range has been designed with easy maintenance in mind. The pump can be easily disassembled to access key components such as the heavy-duty impeller and pump end. This means greater throughput, less downtime and a lower total cost of ownership.
