  • walker Slurry Pump Mechanical Seal

Slurry Pump Mechanical Seal

Model: TJ, THJ, ZWJ, TGJ, L, DT
Pressure: 0-4MPa
Linear velocity: ≤15m/s
Density-: ≤40%
Shaft diameter: Φ20 –Φ 280
Temperature: -20-160°C
Materials: 2Cr13, SS316L
Medium: liquid with solid or crystal
Fit pump models: AH, HH, L, M, G/GH etc

Model: TJ, THJ, ZWJ, TGJ, L, DT
Pressure: 0-4MPa
Linear velocity: ≤15m/s
Density-: ≤40%
Shaft diameter: Φ20 –Φ 280
Temperature: -20-160°C
Materials: 2Cr13, SS316L
Medium: liquid with solid or crystal
Fit pump models: AH, HH, L, M, G/GH etc

Mechanical Seal Model

Materials

Slurry Pump Model

THJ

TWJ-45

TGJ

2Cr13

Silicon carbide

SS316L

1.5/1B-AH

2/1.5B-AH

50B-L

THJ

TWJ-60

TGJ

2Cr13

Silicon carbide

SS316L

3/2C-AH

4/3C-AH

75C-L

1.5/1C-HH

THJ

TWJ-80

TGJ

2Cr13

Silicon carbide

SS316L

3/2D-HH

4/3D-AH

6/4D-AH

6/4D-G

100D-L

THJ

TWJ-100

TGJ

2Cr13

Silicon carbide

SS316L

4/3E-HH

6/4E-AH

8/6E-AH

10/8E-M

8/6E-G

150E-L

THJ

TWJ-130

TGJ



6/4X-HH

10/8S-GH

THJ

TWJ-150

TGJ

2Cr13

Silicon carbide

SS316L

10/8ST-AH

12/10ST-AH

14/12ST-AH

300ST-L

300S-L

450ST-L

THJ

TWJ-170

TGJ

2Cr13

Silicon carbide

SS316L

12/10G-GH

14/12G-G

12/10G-G

14/12T-G



Slurry Pump Mechanical seal is widely used in chemical slurries, alumina plant, FGD systems, power plant ash handling systems, pulp and paper and other industries. The mechanical seal consists of a stationary and a rotating face pressed together under mechanical and hydraulic pressure to prevent leakage. Silicon carbide is the most common material used for manufacture of these seal faces. The use of mechanical seals in slurry applications requires extreme care and attention due to the limited  reliability common in this developing area. Sea costs are relatively high and require substantial justification to warrant their use.

The mechanical seal with no flushing is not suitable for all the conditions. It has very strict usage requirements:
a. the concentration of the slurry could not be too high. It is the best lower than 30%. It could work lower than 40%. If higher than 40%, it is not suggested.
b. the temperature of the slurry could not be too high. It could not higher than 80℃.
c. the particle size could not be too big, which is easy to disturb the mechanical seal work.
d. the slurry is better if it has no or a little crystal. The crystal will disturb the mechanical seal.
e. When slurry pump runs, the liquid should be full in the pump chamber.
