◆ Replaceable wear-resistant metal lining, impeller, sheath, guard plate and over current parts. 1. Long service life, reliable performance and easy operation. 2. The frame plates liner and impeller for type AH, M pumps have replaceable wear-resistant metal liners or rubber liners,The frame plate liner and impeller for HH single stage double suction pumps are adoptable of wear-resistant metal only. 3. The shaft seals Type: Gland seal , Expeller Seal , mechanical Seal. 4. Discharge branch can be positioned at intervals of 45 degrees.
Walker Water Pump Product Introduction:
Two stage centrifugal pump is an important type of centrifugal pump. This type of pump impeller actually consists of two back-to-back impellers, from which the water flow into a volute.
Single stage double suction pumps works just like two same diameter end-suction pumps work at the same time, so its flow quantity can be doubled by using the same outer diameter impeller.
The horizontal split structure of pump shell makes easy inspection and maintenance possible. Meanwhile, the entry end and exit end of double suction pump are in the same direction, being perpendicular to the pump shaft, which is helpful for the layout and installation of pumps and water pipes; double suction pump is characterized by symmetrical impeller structure and non axial force, so it can run more smoothly and can satisfy the operating requirement of mass flow and high lift.
Performance Parameters
Type
Capacity
Head
Speed
Shaft power
m/h
m
r/min
kw
150S-78
160
78
2900
45
150S-50
160
50
2900
27.3
200S-95
280
95
2900
94
200S-63
280
63
2900
59.3
200S-42
280
42
2900
37.7
250S-65
485
65
1450
108.7
250S-39
485
39
1450
62.1
250S-24
485
24
1450
36.9
250S-14
485
14
1450
21.7
300S-90
790
90
1450
249.8
300S-58
790
58
1450
148.5
300S-32
790
32
1450
79
300S-19
790
19
1450
46.9
300S-12
790
12
1450
31.1
350S-125
1260
125
1450
531
350S-75
1260
75
1450
304
350S-44
1260
44
1450
177.6
350S-26
1260
26
1450
101.5
350S-16
1260
16
1450
63.8
500S-13
2020
13
980
86.2
500S-35
2020
35
980
219
500S-98
2020
98
980
678
600S-22
3241
22
980
231.8
600S-75
3060
75
980
694.4
800S-32
5500
32
730
538.5
800S-47
5500
47
730
782.2
Applications
Single stage double suction pumps are widely used in city water supply and drainage, urban water supply; water supply and drainage of central heating system; iron and steel metallurgy, petrochemical refineries, paper mills, oil fields, power plant, airport construction, chemical plants, textile mills, sugar refinery, chemical plant, power plant water supply and drainage, the factory, mine fire water supply system, air conditioning system of water supply, farmland irrigation and drainage; and all other kinds of water engineering.
